SPATIUM S270 SATA 2.5
| Differences are marked in red | SPATIUM S270 SATA 2.5 120GB | SPATIUM S270 SATA 2.5 240GB | SPATIUM S270 SATA 2.5 480GB | SPATIUM S270 SATA 2.5 960GB |
|---|---|---|---|---|
| Model Name | SPATIUM S270 SATA 2.5" | SPATIUM S270 SATA 2.5" | SPATIUM S270 SATA 2.5" | SPATIUM S270 SATA 2.5" |
| Capacity | 120GB | 240GB | 480GB | 960GB |
| Controller | PHISON S11/PHISON S17 | PHISON S11/PHISON S17 | PHISON S11/PHISON S17 | PHISON S11/PHISON S17 |
| Flash Memory | 3D NAND | 3D NAND | 3D NAND | 3D NAND |
| Form Factor | SATA 2.5" | SATA 2.5" | SATA 2.5" | SATA 2.5" |
| Interface | SATA III 6Gbps | SATA III 6Gbps | SATA III 6Gbps | SATA III 6Gbps |
| Compatibility | SATA III (6Gbps) / II (3Gbps) / I (1.5Gbps) | SATA III (6Gbps) / II (3Gbps) / I (1.5Gbps) | SATA III (6Gbps) / II (3Gbps) / I (1.5Gbps) | SATA III (6Gbps) / II (3Gbps) / I (1.5Gbps) |
| Dimensions | 100.20mm (L) x 69.85mm (W) x 7.00mm (H) | 100.20mm (L) x 69.85mm (W) x 7.00mm (H) | 100.20mm (L) x 69.85mm (W) x 7.00mm (H) | 100.20mm (L) x 69.85mm (W) x 7.00mm (H) |
| Sequential Read up to (MB/s) | 500 | 500 | 500 | 500 |
| Sequential Write up to (MB/s) | 360 | 400 | 450 | 450 |
| Random Read 4KB up to (IOPS) | 38,000 | 50,000 | 55,000 | 55,000 |
| Random Write 4KB up to (IOPS) | 72,000 | 80,000 | 80,000 | 80,000 |
| Maximum Operating Power (W) | 1.8 | 1.7 | 2.0 | 2.1 |
| Idle Power PS3 (mW) | 325 | 325 | 335 | 330 |
| Low Power L1.2 (mW) | 4.9 | 4.9 | 4.9 | 4.9 |
| Operating Temperatures | 0°C – 70°C | 0°C – 70°C | 0°C – 70°C | 0°C – 70°C |
| Storage Temperatures | -40°C – 85°C | -40°C – 85°C | -40°C – 85°C | -40°C – 85°C |
| Terabytes Written (TBW) | 40 | 110 | 250 | 500 |
| Mean Time Between Failure (MTBF) | Up to 2,000,000 Hours | Up to 2,000,000 Hours | Up to 2,000,000 Hours | Up to 2,000,000 Hours |
| Limited Warranty | 5 Years, or the coverage for the maximum TBW as stated, whichever comes first. | 5 Years, or the coverage for the maximum TBW as stated, whichever comes first. | 5 Years, or the coverage for the maximum TBW as stated, whichever comes first. | 5 Years, or the coverage for the maximum TBW as stated, whichever comes first. |
| Advanced Features | TRIM (Performance Optimization, OS support required) <br /> SMART (Self-Monitoring, Analysis and Reporting Technology) <br /> LDPC (Low Density Parity Check) ECC Algorithm <br /> Over-Provision | TRIM (Performance Optimization, OS support required) <br /> SMART (Self-Monitoring, Analysis and Reporting Technology) <br /> LDPC (Low Density Parity Check) ECC Algorithm <br /> Over-Provision | TRIM (Performance Optimization, OS support required) <br /> SMART (Self-Monitoring, Analysis and Reporting Technology) <br /> LDPC (Low Density Parity Check) ECC Algorithm <br /> Over-Provision | TRIM (Performance Optimization, OS support required) <br /> SMART (Self-Monitoring, Analysis and Reporting Technology) <br /> LDPC (Low Density Parity Check) ECC Algorithm <br /> Over-Provision |
