Aegis Ti 14th
| Show the Differences |
微星Aegis宙斯盾Ti-14KITU05
|
微星Aegis宙斯盾Ti-14KNUD05
|
微星Aegis宙斯盾Ti-14KNUD07
|
微星Aegis宙斯盾Ti-14KNUE07
|
微星Aegis宙斯盾Ti-14KNUF07
|
微星Aegis宙斯盾Ti-14KNUG09
|
微星Aegis宙斯盾Ti-14KNUI09
|
| 系统 | windows11 家庭中文版 | windows11 家庭中文版 | windows11 家庭中文版 | windows11 家庭中文版 | windows11 家庭中文版 | windows11 家庭中文版 | windows11 家庭中文版 |
|---|---|---|---|---|---|---|---|
| 处理器 | 英特尔14代酷睿i5-14600K处理器 | 英特尔14代酷睿i5-14600KF处理器 | 英特尔14代酷睿i7-14700KF处理器 | 英特尔14代酷睿i7-14700KF处理器 | 英特尔14代酷睿i7-14700KF处理器 | 英特尔14代酷睿i9-14900KF处理器 | 英特尔14代酷睿i9-14900KF处理器 |
| 主板 | 微星 B760M BOMBER WIFI | 微星 B760M BOMBER WIFI | 微星 B760M BOMBER WIFI | 微星 Z790 GAMING PLUS WIFI | 微星 Z790 GAMING PLUS WIFI | 微星 Z790 GAMING PLUS WIFI | 微星 Z790 GAMING PLUS WIFI |
| CPU 风扇 | 240 一体式水冷散热 | 240 一体式水冷散热 | 360 一体式水冷散热 | 360 一体式水冷散热 | 360 一体式水冷散热 | 360 一体式水冷散热 | 360 一体式水冷散热 |
| 显卡 | 集成显卡 | 微星 GeForce RTX4060TI VENTUS 2X BLACK 8G OC(H) | 微星 GeForce RTX4060TI VENTUS 2X BLACK 8G OC(H) | 微星 GeForce RTX 4070 GAMING X SLIM WHITE 12G(H) | 微星 GeForce RTX 4070TI GAMING X SLIM WHTTE 12G(H) | 微星 GeForce RTX 4080 16GB GAMING X TRIO(H) | 微星 GeForce RTX 4090 GAMING X TRIO 24G(H) |
| 系统内存 | 32GB DDR5 5600MHz（16G*2） | 32GB DDR5 5600MHz（16G*2） | 32GB DDR5 5600MHz（16G*2） | 32GB DDR5 6000MHz 白-RGB（16G*2） | 32GB DDR5 6000MHz 白-RGB（16G*2） | 32GB DDR5 6000MHz 白-RGB（16G*2） | 32GB DDR5 6000MHz 白-RGB（16G*2） |
| 有线网络 | 1x RJ45 (2.5G LAN) Realtek RTL8125B | 1x RJ45 (2.5G LAN) Realtek RTL8125B | 1x RJ45 (2.5G LAN) Realtek RTL8125B | 1x RJ45 (2.5G LAN) Realtek RTL8126B | 1x RJ45 (2.5G LAN) Realtek RTL8127B | 1x RJ45 (2.5G LAN) Realtek RTL8128B | 1x RJ45 (2.5G LAN) Realtek RTL8129B |
| 无线网络 | Intel® Wi-Fi 6E module (AX211) | Intel® Wi-Fi 6E module (AX211) | Intel® Wi-Fi 6E module (AX211) | Intel® Wi-Fi 6E module (AX212) | Intel® Wi-Fi 6E module (AX213) | Intel® Wi-Fi 6E module (AX214) | Intel® Wi-Fi 6E module (AX215) |
| 音频 |
Realtek® ALC897 Codec 7.1-Channel High Definition Audio Supports S/PDIF output |
Realtek® ALC897 Codec 7.1-Channel High Definition Audio Supports S/PDIF output |
Realtek® ALC897 Codec 7.1-Channel High Definition Audio Supports S/PDIF output |
Realtek® ALC897 Codec 7.1-Channel High Definition Audio Supports S/PDIF output |
Realtek® ALC897 Codec 7.1-Channel High Definition Audio Supports S/PDIF output |
Realtek® ALC897 Codec 7.1-Channel High Definition Audio Supports S/PDIF output |
Realtek® ALC897 Codec 7.1-Channel High Definition Audio Supports S/PDIF output |
| 視訊輸出 |
1x HDMI™ Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz* 1x D-Sub Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz |
DisplayPort x 3 (v1.4a) HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a) |
DisplayPort x 3 (v1.4a) HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a) |
DisplayPort x 3 (v1.4a) / HDMI™ x 1 (Supports 4K@120Hz HDR,8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a) |
DisplayPort x 3 (v1.4a) HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a) |
DisplayPort x 3 (v1.4a) HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a) |
DisplayPort x 3 (v1.4a) HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a) |
| I/O(前置) |
1 x 重启键 1 x 音频输出 1 x 麦克风 2 x USB 3.2 Gen 1 Type-A 1x 灯控按键 |
1 x 重启键 1 x 音频输出 1 x 麦克风 2 x USB 3.2 Gen 1 Type-A 1x 灯控按键 |
1 x 重启键 1 x 音频输出 1 x 麦克风 2 x USB 3.2 Gen 1 Type-A 1x 灯控按键 |
1 x 重启键 1 x 音频输出 1 x 麦克风 2 x USB 3.2 Gen 1 Type-A 1x 灯控按键 |
1 x 重启键 1 x 音频输出 1 x 麦克风 2 x USB 3.2 Gen 1 Type-A 1x 灯控按键 |
1 x 重启键 1 x 音频输出 1 x 麦克风 2 x USB 3.2 Gen 1 Type-A 1x 灯控按键 |
1 x 重启键 1 x 音频输出 1 x 麦克风 2 x USB 3.2 Gen 1 Type-A 1x 灯控按键 |
| I/O(後置) |
HDM VGA DisplayPort Keyboard / Mouse 2.5G LAN Wi-Fi / Bluetooth Audio Connectors USB 2.0 USB 3.2 Gen 1 5Gbps (Type-A) |
HDM VGA DisplayPort Keyboard / Mouse 2.5G LAN Wi-Fi / Bluetooth Audio Connectors USB 2.0 USB 3.2 Gen 1 5Gbps (Type-A) |
HDM VGA DisplayPort Keyboard / Mouse 2.5G LAN Wi-Fi / Bluetooth Audio Connectors USB 2.0 USB 3.2 Gen 1 5Gbps (Type-A) |
DisplayPort x 3 ，HDMI™ x 1 ， USB 3.2 Gen 1 5Gbps Type-A USB 3.2 Gen 2 10Gbps Type-A USB 3.2 Gen 2 10Gbps Type-A 2.5G LAN Port Wi-Fi / Bluetooth Antenna HD Audio Connectors Flash BIOS Button HDMI™ 1.4 Port USB 3.2 Gen 2 10Gbps Type-C USB 3.2 Gen 1 5Gbps Type-A Optical S/PDIF OUT |
DisplayPort x 3 ，HDMI™ x 1 ， USB 3.2 Gen 1 5Gbps Type-A USB 3.2 Gen 2 10Gbps Type-A USB 3.2 Gen 2 10Gbps Type-A 2.5G LAN Port Wi-Fi / Bluetooth Antenna HD Audio Connectors Flash BIOS Button HDMI™ 1.4 Port USB 3.2 Gen 2 10Gbps Type-C USB 3.2 Gen 1 5Gbps Type-A Optical S/PDIF OUT |
DisplayPort x 3 ，HDMI™ x 1 ， USB 3.2 Gen 1 5Gbps Type-A USB 3.2 Gen 2 10Gbps Type-A USB 3.2 Gen 2 10Gbps Type-A 2.5G LAN Port Wi-Fi / Bluetooth Antenna HD Audio Connectors Flash BIOS Button HDMI™ 1.4 Port USB 3.2 Gen 2 10Gbps Type-C USB 3.2 Gen 1 5Gbps Type-A Optical S/PDIF OUT |
DisplayPort x 3 ，HDMI™ x 1 ， USB 3.2 Gen 1 5Gbps Type-A USB 3.2 Gen 2 10Gbps Type-A USB 3.2 Gen 2 10Gbps Type-A 2.5G LAN Port Wi-Fi / Bluetooth Antenna HD Audio Connectors Flash BIOS Button HDMI™ 1.4 Port USB 3.2 Gen 2 10Gbps Type-C USB 3.2 Gen 1 5Gbps Type-A Optical S/PDIF OUT |
| 存储 | 1TB NVMe SSD | 1TB NVMe SSD | 1TB NVMe SSD | 1TB NVMe SSD | 2TB NVMe SSD | 2TB NVMe SSD | 2TB NVMe SSD |
| 电源适配器 | 微星 A750GF 750W | 微星 A750GF 750W | 微星 A750GF 750W | 微星 A750GF 750W | 微星MPG A850GL 850W | 微星MPG A850GL 850W | 微星MPG A1000G 1000W |
| 尺寸 | 472.5mm(L)*210mm(W)*498mm(H)mm | 472.5mm(L)*210mm(W)*498mm(H)mm | 472.5mm(L)*210mm(W)*498mm(H)mm | 472.5mm(L)*210mm(W)*498mm(H)mm | 472.5mm(L)*210mm(W)*498mm(H)mm | 472.5mm(L)*210mm(W)*498mm(H)mm | 472.5mm(L)*210mm(W)*498mm(H)mm |
| 重量 | 0 | 0 | 0 | 0 | 0 | 0 | 0 |
| 保固 | 3年上门服务 | 3年上门服务 | 3年上门服务 | 3年上门服务 | 3年上门服务 | 3年上门服务 | 3年上门服务 |
