PRO MAX 241PHW E14
54~169.78 KHz(H) / 48~144 Hz(V)
93% / 96% / 122% (CIE1976)
HDR Ready
2x USB 5Gbps Type-A
1x USB 5Gbps Type-B
1x USB 5Gbps Type-B
1x Headphone-out
2x 3W
300 cd/m2
Adaptive-Sync
541.93 x 200.81 x 381.11mm
(21.34 x 7.91 x 15.00 inch)
(21.34 x 7.91 x 15.00 inch)
541.93 x 65.44 x 322.28 mm
(21.34 x 2.58 x 12.69 inch)
(21.34 x 2.58 x 12.69 inch)
814 x 149 x 410 mm
(32.05 x 5.87 x 16.14 inch)
(32.05 x 5.87 x 16.14 inch)
0 ~ 110 mm
-90° ~ 90°
-30° ~ 30°
1x HDMI™ Cable (2.0b), 1x Type-C Cable (3.2 Gen 1), 1x USB Type-B to A Cable (3.2 Gen 1), 1x Power Cord, 1x Quick Guide, 4x VESA Wall Mount Screw, Color Report, 1x Cable Clip
23.8"
1920 x 1080 (FHD)
144Hz
1ms (MPRT) / 4ms (GTG)
IPS
100~240V, 50/60Hz
178°(H) / 178°(V)
16:9
1500:1
527.04(H) x 296.46(V)
0.2745(H) x 0.2745(V)
Anti-Glare with Circular Polarization
16.7M
8 bits (6 bits + FRC)
1x HDMI™ 2.0b (FHD@144Hz)
1x DisplayPort 1.2a
1x Type-C (DP alt.) w/ 65W PD
1x DisplayPort 1.2a
1x Type-C (DP alt.) w/ 65W PD
Yes
75 x 75 mm
Internal Power Board
-5° ~ 20°
5.35 kg (11.79 lbs) / 8 kg (17.64 lbs)
HDMI™: 1920 x 1080 (Up to 144Hz)
DisplayPort: 1920 x 1080 (Up to 144Hz)
Type-C: 1920 x 1080 (Up to 144Hz)
Delta-E (△E) ≤ 2
Support: HDMI™ CEC / MSI Power Link, KVM 1.0, FW Update; Non-Support: PIP/PBP
DisplayPort: 1920 x 1080 (Up to 144Hz)
Type-C: 1920 x 1080 (Up to 144Hz)
Delta-E (△E) ≤ 2
Support: HDMI™ CEC / MSI Power Link, KVM 1.0, FW Update; Non-Support: PIP/PBP
