Modern AM272 12M
Modern AM272 12M-083CN
|
|
| 操作系统 | Windows 11 Home |
|---|---|
| CPU Number | Intel Core i7-1260P |
| CPU Clock | 2.1GHz |
| CPU Cores | 12 |
| TDP | 28W |
| Cache | 18 MB Intel® Smart Cache |
| Threads | 16 |
| Max Turbo Frequency | up to 4.70 GHz |
| Chipsets | SoC |
| 内存 |
Memory Size 16GB(8GB*2) Memory Type DDR4 SDRAM Module Type SO-DIMM Memory Slot(Total) 2 Memory Slot(Free) 0 Max Capacity Max 64GB |
| SSD Interface | PCIe GEN3x4 |
| 存储 |
SSD Form Factor M.2-2280 M-KEY(512GB*1) SSD Size 512GB M.2 slots(Total) 1 M.2 slots(Free) 0 2.5" Drive Bays(Total) 1 2.5" Drive Bays (Free) 1 3.5" Drive Bays(Free) 0 |
| 音频 | Realtek ALC256, 2.1 Channel HD Audio |
| LAN | Realtek RTL8111H |
| WLAN Version | 802.11ax 2x2+BT |
| BT Version | 5.2 |
| WLAN | INTEL/AX201.NGWG.NVW |
| I/O 接口 (前) |
2 x USB 3.2 Gen 2 Type A 2 x USB 3.2 Gen 2 Type C |
| Mic-in/Headphone-out combo | 1 |
| USB 2.0 Type A (R) | 2 |
| RJ45 | 1 |
| VGA out | 1 |
| HDMI out | 1x (v2.0) |
| AC Adapter Output | 120W |
| Adjustment (Tilt) | -5~15 |
| Lock type | Kensington |
| Weight (Net kg) | 6 |
| Weight (Gross kg) | 8.7 |
| Product Dimension with Holder (WxDxH) (mm) | TBD x TBD x TBD |
| Product Dimension with Holder (WxDxH) (inch) | TBD x TBD x TBD |
| Inside Carton Dimension with Stand (WxDxH) (mm) | 714 x 200 x 482 |
| Inside Carton Dimension with Stand (WxDxH) (inch) | 28.11 x 7.87 x 18.98 |
| Product Dimension with Stand (WxDxH) (mm) | 611.75 x 175.09 x 443.42 |
| Product Dimension with Stand (WxDxH) (inch) | 24.08 x 6.89 x 17.46 |
| Operating, Storage Temperature | 0° C ~ 35° C ; -20° C ~ 60° C |
| Operating, Storage Humidity | 0% ~ 85%;0% ~ 90% |
| Regulatory Compliance | FCC(Class B), CB/CE, UL(CUL), BSMI, VCCI, RCM(C-Tick) |
| Warranty | 36months |
| Keyboard Interface | WIRELESS |
| Mouse Interface | WIRELESS |
| Power Cord | 1 |
| AC Adaptor | 1 |
| Warranty Card | 2 |
| Quick Guide | 1 |
| Keyboard | RF1430 |
| Mouse | MA04 |
| EAN | 4719072966973 |
| UPC | 824142290552 |
| Part No | 9S6-AF8211-083 |
| UCC14 | 10824142290559 |
| MKT Name | Modern AM272 12M |
| MKT Spec | Modern AM272 12M-083CN |
| Color | ID1/Black-Black-Black |
| Model | AF82 |
| Weight (Net lbs) | 13.23 |
| Weight (Gross lbs) | 19.18 |
